Carbon Steel Gas Ball Valve, 2-24 Inch, 150-2500 LB, RF

Carbon Steel Gas Ball Valve Fabricator: API 6D Ball Valve for Gas, Carbon Steel, 2-24 IN, 150-2500LB, RF, Electro Hydraulic or Gas-over-oil Actuator.

Categories: Trunnion Ball Valves

Tags: Carbon Steel Ball Valve , Gas Ball Valve , API 6D Ball Valve

Request a quote

Detail Information

NAME: GAS BALL VALVE.
DESIGN AND MANUFACTURE: API 6D.
INSPECTION AND TEST: API 6D.
END FLANGE DIMENSION: ASME B16.5.
F-T-F DIMENSION: API 6D.
PRESSURE-TEMPERATURE: ASME B16.34.
DESIGN TEMP.: -29℃-150℃.
NOMINAL DIAMETER: 2-24 Inch.
DESIGN STANDARD: CLASS 150-2500 LB.

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal Diameter: 2 - 60 Inch (DN50-DN1500).
End Connection: BW, Flanged.
Pressure Range: 150 - 2500 LB (PN16-PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃-+200℃.
